Solvent Recovery Unit

Get a Price/Quote

Product Details:

Operate Method AUTOMATIC
Temperature 150C
Product Type Solvent Recovery Unit
Power Supply A/C POWER SUPPLY
Color Silver
Dimension (L*W*H) 400 x 320 x 650 mm Millimeter (mm)
Usage It is a process system that takes effluent and extracts useful solvents and raw materials back out of the process waste stream
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Solvent Recovery Unit Price And Quantity

Minimum Order Quantity 1 Piece

Solvent Recovery Unit Product Specifications

Color Silver
Control Mode Digital
Dimension (L*W*H) 400 x 320 x 650 mm Millimeter (mm)
Usage It is a process system that takes effluent and extracts useful solvents and raw materials back out of the process waste stream
Material Metal
Voltage 220-240V Volt (v)
Power 1200 W Watt (w)
Machine Weight 17 Kg approx. Kilograms (kg)
Application Industrial, Laboratory
Product Type Solvent Recovery Unit
Temperature 150C
Operate Method AUTOMATIC
Power Supply A/C POWER SUPPLY

Solvent Recovery Unit Trade Information

Supply Ability 20 Piece Per Month
Delivery Time 3-4 Days
Main Domestic Market All India

Product Description

On-flammable solvent liquids used for the binder extraction test can be successfully recovered using the solvent recovery unit. The recovery unit consists of two stainless steel chambers, one for the dirty used solvent and the other for the cleaned recovered solvent. Solvent in the left-hand side chamber is distilled by an electrical heater and then passes through a water cooling system and drops into the second chamber ready for re-use. A temperature switch automatically stops the heating elements when the recovery process is completed. The unit is supplied complete with 10 m plastic tubing, tube clamps, sieve insert 0.6mmopening

The solvent recovery unit is supplied complete with:

Plastic tubing, 10 m
Sieve insert, 0.6 mm

Specifications:

Dimensions : 400 x 320 x 650 mm
Weight (approx.) : 17 Kg
Power : 1200 W
Max. Temperature : 150 degree C
