Solvent Recovery Unit

Solvent Recovery Unit

Product Details:

  • Power Supply A/C POWER SUPPLY
  • Voltage 220-240V Volt (v)
  • Power 1200 W Watt (w)
  • Dimension (L*W*H) 400 x 320 x 650 mm Millimeter (mm)
  • Temperature 150C
  • Product Type Solvent Recovery Unit
  • Material Metal
  • Click to View more
X

Solvent Recovery Unit Price And Quantity

  • 1 Piece

Solvent Recovery Unit Product Specifications

  • It is a process system that takes effluent and extracts useful solvents and raw materials back out of the process waste stream
  • Digital
  • Silver
  • Industrial, Laboratory
  • AUTOMATIC
  • 150C
  • 400 x 320 x 650 mm Millimeter (mm)
  • Solvent Recovery Unit
  • Metal
  • 1200 W Watt (w)
  • 17 Kg approx. Kilograms (kg)
  • 220-240V Volt (v)
  • A/C POWER SUPPLY

Solvent Recovery Unit Trade Information

  • 20 Piece Per Month
  • 3-4 Days
  • All India

Product Description

On-flammable solvent liquids used for the binder extraction test can be  successfully recovered using the solvent recovery unit. The recovery unit consists of two stainless steel chambers, one for the dirty used solvent and the other for the cleaned recovered solvent. Solvent in the left-hand side chamber is distilled by an electrical heater and then passes through a water cooling system and drops into the second chamber ready for re-use. A temperature switch automatically stops the heating elements when the recovery process is completed. The unit is supplied complete with 10 m plastic tubing, tube clamps, sieve insert 0.6mmopening

The solvent recovery unit is supplied complete with:



  • Plastic tubing, 10 m
  • Sieve insert, 0.6 mm



Specifications:

  • Dimensions : 400 x 320 x 650 mm
  • Weight (approx.) : 17 Kg
  • Power : 1200 W
  • Max. Temperature : 150 degree C
